Top chord connections.
Bottom chord connections.
Hip vertical and connection details. The hip vertical is a star-shape beam, a special design of beam that tends to show up only on very old truss bridges.
Builder plaques on south end of bridge.
Views of the triple intersection configuration.
Overview of bracing.
Sway bracing.
Portal bracing detail.
Vertical members.
Pole railings on bridge.
Vertical members.
End post.
Base of end post appears to show the rusted remains of a roller bearing nest.
Floor beams.
Views of the vertical members from unknown bridge used to block off the Triple Whipple Bridge.
Sign, located near the new IN-56 Bridge.
